Averaging Flow Sensor:
|Length||12-1/2" to 23-29/32" (31.75 to 60.72 cm)|
|Sensing points||Up to 10|
|Models||PAFS-1006 to PAFS -1011|
|Accommodate box diameter||4" to 16" (10.16 to 40.64 cm)|
The Series PAFS-1000 Averaging Flow Sensor is ideal for sensing differential pressure in the inlet section of variable air volume terminal units and fan terminal units. Units can also be used to sense differential pressure at other locations in the main or branch duct systems.
The "H" port senses total pressure and the "L" port senses static pressure. The difference between these signals is the differential or velocity pressure.
Series 160S "S" Type Stainless Steel Pitot Tube:
|Tube diameter||5/16 inch|
|Connection type||1/8 inch Female NPT connections|
|Tube inner diameter||1/8 to 3/16 inch|
Series 160S Pitot Tubes are designed specifically for flow measurement of dirty, particulate-laden air or gas streams typical of the smokestack and another environmental testing. Large diameter stainless steel tubing resists plugging under harsh, sooty conditions which quickly block conventional flow sensors. Total and static pressure tubes are precisely aligned and welded together every six inches for maximum accuracy, strength and long-term durability. Versatile female NPT connections easily adapt to any type of pipe or tubing. A pair of I.D. tubing adapters is included plus a handy molded vinyl cap to protect tip when not in use. Supplied with complete instructions.
Permanent Mounting (PM) models include welded stainless steel sleeve and adjustable compression fitting with male 1-including threads. Adjust depth, lock in place.
Dwyer Digital Calibration Pressure Gauge:
|Product type||Calibration Pressure Gauge|
|Material grade||316 SS|
Dwyer Digital Calibration Pressure Gage with accuracy, Wetted parts and calibration capabilities. With accuracy and large 5 digit resolution, this gage can be used in a critical industrial application where precision is most important.
-Field gage calibration
-Burnt disc testing
-Torque data logging
-Pressure regulator testing
-To be used with the pressure pump for calibration
